Radium 12AN ORB to 12AN Male Remote Fitting
Radium 12AN ORB to 12AN Male Remote Fitting
Universal fit
No vehicle selection needed.
This part may still fit. Check the details below or contact us before ordering. Ask about fitment
Fitment not confirmed
This part may still fit. Check the details below or contact us before ordering. Ask about fitment
In Melbourne? Fit it in our workshop.
We fit parts in-house at the RevZone workshop. Book a time and bring your car in.
Description
Remote mounting adapter fitting engineered by Radium Engineering to convert 12AN ORB (O-Ring Boss) ports to 12AN male connections. This fitting enables remote mounting of external quick-fill DSV (Dry Sump Valve) systems off the fuel cell, providing flexible installation options for high-performance fuel systems.
Compatibility
- Radium 20-049X-XX FCST (Fuel Cell Surge Tank) - secures directly into 12AN ORB vent port
- Older FCST units - use in conjunction with 20-0439 12AN ORB to 5-Bolt SAE Adapter
Key Features
- ✓ 12AN ORB to 12AN male conversion
- ✓ Enables remote mounting of external quick-fill DSV
- ✓ Direct installation into FCST 12AN ORB vent port
- ✓ CNC-machined construction for precise fitment
- ✓ Anodized finish for corrosion resistance
- ✓ E85 and all fuel types compatible
- ✓ Professional-grade motorsport component
- Application: Radium FCST remote quick-fill mounting
- Part Number: 14-0434
- Inlet: 12AN ORB (3/4"-16 O-Ring Boss)
- Outlet: 12AN male
- Construction: CNC-machined aluminum
- Fuel Compatibility: Gasoline, E85, and alternative fuels
Applications
Ideal for remotely mounting external quick-fill DSV systems off Radium fuel cell surge tanks. Perfect for motorsport applications requiring flexible quick-fill system placement for optimal accessibility and installation clearance.
Benefits
- Enables remote mounting of quick-fill systems
- Direct installation into FCST vent port
- CNC-machined precision ensures leak-free fitment
- Compatible with current and older FCST models
- Anodized finish provides long-term durability
- Professional motorsport-grade construction
Important Note: For older FCST units, use in conjunction with 20-0439 12AN ORB to 5-Bolt SAE Adapter. For current 20-049X-XX FCST models, secures directly into 12AN ORB vent port.
Fast shipping available throughout Australia. Lead times may vary - contact us for current availability.
Specifications
- Part Number
- 14-0434
- Brand
- Radium Engineering
